Dahua Europe ASI1212A(V2) Basic access control reader Black,Grey
Code: ART-146253 6939554947995 ASI7223X-A-T1
- Touch keyboard and LCD display
- Support 30,000 valid cards & 150,000 records
- Support multiple cards(default IC card) (“-D” means ID EM card)
- Support card, password, fingerprint and combination
- TCP/IP to PC
- Wiegand or RS-485 interface to reader
- Door time out alarm, intrusion alarm, duress alarm and tamper alarm
- Anti-pass back, multi-card open
- Software attendance
- Support 128 efficient time and holiday schedules
- Watch dog function ensure device free from halting
- Support 30,000 valid cards & 150,000 records
- Support multiple cards(default IC card) (“-D” means ID EM card)
- Support card, password, fingerprint and combination
- TCP/IP to PC
- Wiegand or RS-485 interface to reader
- Door time out alarm, intrusion alarm, duress alarm and tamper alarm
- Anti-pass back, multi-card open
- Software attendance
- Support 128 efficient time and holiday schedules
- Watch dog function ensure device free from halting
Tech Detail Table
Tech Detail Table
| Access chip/card reader | Y |
| Access chip/card reader type | Contactless |
| Access code reader | N |
| Alarm function | Y |
| Anti-passback | Y |
| Attendance function | Y |
| Authentication type | Access chip/card, Password |
| Backlight | Y |
| Built-in display | Y |
| Built-in processor | Y |
| Cards capacity | 30000 cards |
| Colour of product | Black, Grey |
| Contactless working distance | 8 cm |
| Depth | 191 mm |
| Display type | LCD |
| False Acceptance Rate (FAR) | 0.00004% |
| False Rejection Rate (FRR) | 0.15% |
| Fingerprint reader | Y |
| Height | 32 mm |
| International Protection (IP) code | IP55 |
| Keypad illumination | Y |
| Number of groups | 128 |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| PC connected | Y |
| PC connection | RS-485/RJ-45 |
| Power consumption | 200 mA |
| RFID frequency | 12.56 MHz |
| RS-485 ports | 1 |
| Tamper switch detector | Door time out alarm, Intrusion alarm, Duress alarm,\nTamper alarm |
| Type | Basic access control reader |
| Watch Dog function | Y |
| Weight | 700 g |
| Width | 158 mm |
